EG1600

remote control concrete floor grinder grinding polishing machine

Product/User Benefits:
* Increased productivity and grinding performance
* Easy handling thanks to ergonomic control elements, fixed speed as well as low noise and vibration levels
* Fatigue-proof working and reduction of side forces because of outstanding machine balance
* Maximum durability and load capacity due to very robust construction
* Impressive mobility as well as trouble-free transportation thanks to detachable machine parts
* Time saving patented quick tool fixing system
* Dust-free operation because of floating cover in combination with reliable dust collection system

Fields of applications:
* Grinding concrete/epoxy floor/ solidified floor/ terrazzo floor /granite floor /natural marble floor /diamond abrasion
resistant floor /self leveling cement,etc ,places requiring surface treatment
* Removal of paint, epoxy, glue and other coatings from concrete
* Preparation of concrete for installation of new flooring/coating
* Elimination of irregularities in concrete
* Repair of damaged concrete
* Sealing preparation
* Renovation works

Product Features:
* It is safer to use IP67 waterproof and dustproof power plug
* High-power heavy-duty body can improve the cutting rate of ground, the ash output is large and the efficiency is high.

The back-and-forth reversible counterweight iron is adaptable to a variety of surfaces.Achieve double efficiency, perfect effect!
* Famous brand frequency converter with super variable speed control function ensures the machine work steady
* Original patented retractable compensation structure, suitable for uneven ground, reduce dust and flying stone, improve
construction environment safety
* With toolbox, portable storage of accessories
* The frequency conversion motor can meet the grinding requirements of industrial floor for a long time and heavy task,

and can work continuously for 24 hours.
* Multi-functional magnetic disc is convenient to install, limit pile locking disc, construction is safer
*Fault detection, through the fault code according to the reference table to find out the corresponding problems

Specification:

Model

EG1600 remote control

Working Area

1600mm

Voltage

380-440V three phases

Grinding Motor Power

15kw*2

Inverter power

18.5kw*2

Walking motor power

1.5kw*2(servo)

Walking speed

0-15m/min

HZ

50/60HZ

AMP

56A

Type

Gear driven type

Grinding plate RPM/Min

0-1500

Weight

1300kg

Grinding disk size

280mm*8

Packing size

190*240*103cm

Cable

3*10+1*6


Specification:

Model

EG1600 remote control

Working Area

1600mm

Voltage

380-440V three phases

Grinding Motor Power

15kw*2

Inverter power

18.5kw*2

Walking motor power

1.5kw*2(servo)

Walking speed

0-15m/min

HZ

50/60HZ

AMP

56A

Type

Gear driven type

Grinding plate RPM/Min

0-1500

Weight

1300kg

Grinding disk size

280mm*8

Packing size

190*240*103cm

Cable

3*10+1*6


Iron frame+Polywood case
